Update 26.02.04

A new update has been released, you can view the full changes on our blog post.

https://sbox.game/news/update-26-02-04

Changelog

🎁 Added

• Mapping snapping

• Mapping: flip mesh

• Mapping: box select & lasso selection

• LengthOverride property @ubre

• GPU Profiler overlay

• TreeView extras

• Navmesh baking

🧼 Improved

• Navmesh memory optimizations: improved by at least 5 times

• Hi-res screenshots use global anti-aliasing setting

• Mapping Tool "Save As Model" uses the model origin & supports more collision types

• Swapchain creation now uses SDL to handle surface creation, try to be more sane about format

• Swapchain depth format is simplified as always being D32FS8, with additional required flags

• DDGI uses RG1616F instead of BC6H because block compression caused too many artifacts

• Navmesh polygon mesh generation is 20-30% faster

• DDGI gizmo probes load relocation positions from relocation texture

• Use native C implementation for LZ4 managed compression API, used by networking

• Error handling for nested prefabs when a prefab is missing

• Foliage uses alpha to coverage for MSAA

• Steam callbacks run in network thread to prevent disconnects whilst main thread is busy (loading resources)

• Indirect light volumes use two passes bounce by default for higher quality

• Keep MainThread responsive when loading navmesh in editor

• Big VR cleanup

• DDGI: Stability improvement for ComputeVisibility @RedPixel

• Logs now archive when old or go over 512MB @766974616c79

🪛 Fixed

• Crash: CLoadingResource::FinalizeLoadRequest with cyclical dependencies

• Crash: ResourceType overflow (too many GameResources) causing a buffer overrun and resource system corruption

• PlayerController animation events not reenabling when component is reenabled

• Navmesh CalculatePath giving up early on complex paths

• Not being able to frame to objects while in ejected viewport

• Nudge direction being inverted

• Auto-closing restore scene tabs on startup

• Terrain buffer leaking if disabled or deleted

• Terrain buffer reading has a HasTerrain check now

• Memory usage is measured with WorkingSet instead of PrivateMemorySize

• Vulkan robustness correctly uses pipeline robustness alongside now

• Null GPU buffer descriptors are now "bound" correctly with VK_WHOLE_SIZE range

• Error shader had mismatched descriptor set layouts between the vertex and pixel shader, potential GPU crash

• Editor swapchains matching screen resolution forcing exclusive fullscreen on Nvidia

• Titlebar switching back to fallback thumbnail after publshing

• Screen recording failing with ScenePanels

• MovieMaker: Session nav widgets not always being visible

• MovieMaker: Additive keyframe editing when source block starts at T=0

• MovieMaker: Timeline vibrating when trying to pan too far left

• MovieMaker: When dragging in timeline, scrub if we drag off the edge

• Indirect light volumes copy depth to color using compute, a Graphics.CopyTexture was not suitable because of different image formats

• CookieContainer not auto saving properly

• Renaming assets causing duplicate AssetListEntry selection

• GameObjectSystems not serializing on global systems, and deserialization failing for non-trivial types

• Glass shader not supporting orthographic projection properly for refaction

• StickyPopup height being awful

• Quad overdraw not working

• Occasional double context menu on searchable menus

• CodeGen compiler warnings related to [Sync] when using nullable @Remscar
