40Hz Processor/CPU With Software Calculator Program-Card Installed (8-Bit)

THANK YOU ALL FOR 4K SUBS AND EVERYTHING!!

Leave a comment about what you think and dont forget to :D

Watch a quick how to use/preview here !

Check out the CPU used to make this (that i also made) here !

Note: Only 1 mod used and is necessary for this creation, without "Circuit Creator" mod this would be literally impossible.

BIG THANKS TO Vincling for helping me alot through this project!

Check out his workshop! and his epic mod! :D

---

Introduction:

Hi!

i made a software calculator program that runs on my 40hz processor, the program can add, subtract, multiply and 𝗱𝗶𝘃𝗶𝗱𝗲 any two 8-bit numbers using the power of software and processors!!

---

How to use:

** Face the side shown on the picture on steam (the side with the big vertical panel and switches)! **

Inputs

Data Inputs

1.  **Bright Lime Green Switches Row: Input 1, its the minuend and the dividend.**

2.  **Dark Lime Green Switches Row: Input 2, its the subtrahend and the divisor.**

Control Inputs

3.  **Yellow Switch: Start the CPU.**

4.  **White Button: Reset All Registers (will reset both the CPU and the program card). **

5.  ** Red "Plus" Switch: Add Both Inputs. **

6.  ** Blue "Minus" Switch: Subtract Input 2 from Input 1.**

7.  ** Green "Multiply "Switch: Multiply both inputs.**

8.  ** Yellow "Divide" Switch: Divide Input 1 over Input 2**

-

Output

1.  ** Dark Red Logic Gates Row: This will be the output for all operations!**

---

Notes/Warnings:

• ** MAKE SURE TO RESET EVERYTHING (with white button) BEFORE RUNNING FIRST TIME! **

• ** Do NOT have more than 1 operation switch on at once.**

• ** Do NOT activate any operation switch while the cpu is running.**

• ** Do NOT edit any of the 8-Bit inputs while the cpu is running, could break it.**

• ** To run again you MUST press the reset button.**

• ** If anything breaks or is behaving weirdly then resetting (white button) should fix it.**

• ** Dividing by 0 will put the cpu on an infinite sequence of adding 1s, dont do it unless you wanna humiliate the cpu ;)**

---

Thats it :D!

**If you like it check out my workshop for more awesome creations :D **
